Busch Pumps

Oil Lubricated Rotary Vane Vacuum Pumps

Model  M3/H
50Hz / 60Hz		 Max Vacuum mbar Abs
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
R5 PB0003A 3 / 3.6 2 0.1 / 0.1
R5 PC0003A 3 / 3.6 15 0.1 / 0.1
R5 PB0008A 8/ 9.6 2 0.35 / 0.45
R5 PC0008A 8 / 9.6 30 0.35 / 0.45
R5 0006C 6 / 7.2 2 0.37
R5 0006E 6 / 7.2 2 0.37
R5 0010B  RA Version 10 / 12 0.5 0.37 / 0.55
R5 0010B  RC Version 10 / 12 20 0.37 / 0.55
R5 0021B  RA Version 20 / 24 2 0.75
R5 0021B  RC Version 20 / 24 20 0.75
R5 0025E  RA Version 25 / 30 0.5 0.75 / 1.1
R5 0025E  RC Version 25 / 30 20 0.75 / 1.1
R5 0040E  RA Version 40 / 48 0.5 1.1 / 1.5
R5 0040E  RA Version 40 / 48 20 1.1 / 1.5
R5 0063E  RA Version 63 / 76 0.5 1.5 / 2.2
R5 0063E  RC Version 63 / 76 20 1.5 / 2.2
R5 0100E  RA Version 100 / 120 0.5 2.2 / 3.0
R5 0100E  RC Version 100 / 120 20 2.2 / 3.0
RA R5 0160D 160 / 190 0.1 4 / 5.5
RA R5 0202D 200 / 240 0.1 4 / 5.5
RA R5 0250D 250 / 300 0.1 5.5 / 7.5
RA R5 0302D 300 / 360 0.1 5.5 / 7.5
RA R5 0400B 400 / 480 0.1 11 / 15
RA R5 0502B 500 / 600 0.1 11 / 15
RA R5 0630B 630 / 700 0.1 15 / 18.5
R5 0165D 160 / 190 0.1 4 / 5.5
R5 0205D 200 / 240 0.1 4 / 5.5
R5 0255D 250 / 300 0.1 5.5 / 7.5
R5 0305D 300 / 360 0.1 5.5 / 7.5
RA R5 1000B 1000 / 1200 0.1 22 / 30
RA R5 1600B 1600 / 1920 0.1 30 / 37

Back to top

Busch R5 RA0100F

Busch  R5 RA0250D

Busch  R5 RA0630B

Aqua Oil Lubricated Rotary Vane Vacuum Pumps

Model  M3/H
50Hz / 60Hz		 Max Vacuum mbar Abs
50Hz / 60Hz
Aqua R5 0025E 25 < 5
Aqua R5 0040E 40 < 5
Aqua R5 0063E 63 < 5
Aqua R5 0100E 100 < 5
Aqua R5 0165D 160 < 5
Aqua R5 0205D 200 < 5
Aqua R5 0255D 250 < 5
Aqua R5 0305D 300 < 5
Aqua R5 0400B 400 < 5
Aqua R5 0502B 500 < 5
Aqua R5 0630B 630 < 5

Back to top

Mink Rotary Lobe Vacuum Pumps

Model  M3/H
50Hz / 60Hz		 Max Vacuum mbar Abs
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
MI 1124BV 65 / 80 100 1.5 / 2.2
MI 1122BV 140 / 165 100 3 / 4
MI 1354BV 165 / 195 250 3 / 4
MI 1504BV 250 / 290 250 4 / 5.5
MI 1352BV 340 / 390 250 7.5 / 9.2
MI 1502BV 500 / 580 250 9.2 / 15

Back to top

Mink Rotary Lobe Compressor

Model  M3/H
50Hz / 60Hz		 Max Pressure BAR (G)
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
MI 1124BP 65 / 80 0.5 / 0.5 1.5
MI 1124BP 65 / 80 1.0 / 0.7 2.2
MI 1124BP 65 / 80 1.5 / 1.2 3.0
MI 1124BP 65 / 80 2.0 / 1.7 4.0
MI 1122BP 140 / 165 0.7 4.0    50Hz
MI 1122BP 140 / 165 1.3 / 0.8 5.5
MI 1122BP 140 / 165 2.0 / 1.5 7.5
MI 1122BP 140 / 165 2 9.2   60Hz
MI 1354BP 165 / 195 0.6 4.0    50Hz
MI 1354BP 165 / 195 1.0 / 0.6 5.5
MI 1354BP 165 / 195 1.6 / 1.2 7.5
MI 1354BP 165 / 195 2.0 / 1.7 9.2
MI 1354BP 165 / 195 2 11    60Hz
MI 1504BP 250 / 290 0.8 7.5    50Hz
MI 1504BP 250 / 290 1.2 / 0.8 9.2
MI 1504BP 250 / 290 1.6 / 1.4 11
MI 1504BP 250 / 290 2.0 / 2.0 15
MI 1352BP 340 / 390 0.9 11    50Hz
MI 1352BP 340 / 390 1.7 / 1.1 15
MI 1352BP 340 / 390 2.0 / 1.7 18.5
MI 1352BP 340 / 390 2 22     60Hz
MI 1502BP 500 / 580 0.8 15    50Hz
MI 1502BP 500 / 580 1.2 / 0.8 18.5
MI 1502BP 500 / 580 1.6 / 1.2 22
MI 1502BP 500 / 580 2.0 / 1.6 30

Back to top

Mink Rotary Claw Vacuum Pump MM1104 – MM1142BV MM1324 – MM1322AV

Model  M3/H
50Hz / 60Hz		 Max Vacuum mbar Abs
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
MM 1104BV 62 / 75 60 1.1 / 1.5
MM 1144BV 78 / 96 60 1.5 / 2.2
MM 1102BV 105 / 135 60 2.2 / 3.0
MM 1142BV 140 / 175 60 3.0 / 4.0
MM 1324AV 160 / 192 60 3.0 / 3.6
MM 1202AV 200 / 240 100 4.0 / 4.8
MM 1252AV 250 / 300 100 4.5 / 5.5
MM 1322AV 300 / 360 150 5.5 / 6.5

Back to top


Busch MM1252AV

Mink Rotary Claw Compressor MM1104 – MM1142BP MM1202 – MM 1322AP

Model M3/H
50Hz / 60Hz		 Max Pressure BAR (G)
50Hz / 60Hz		 Motor Size KW
50Hz/60Hz
MM 1104BP 62 / 75 1.2 / 0.8 2.2
MM 1104BP 62 / 75 1.8 / 1.4 3.0
MM 1104BP 62 / 75 2.0 / 2.0 4.0
MM 1144BP 78 0.8 2.2 50Hz
MM 1144BP 78 / 96 1.4 / 0.8 3.0
MM 1144BP 78 / 96 2.0 / 2.0 4.0
MM 1102BP 105 0.7 4.0 50Hz
MM 1102BP 105 / 135 1.4 / 0.8 5.5
MM 1102BP 105 / 135 2.0 / 1.5 7.5
MM 1102BP 135 2 8.6 60Hz
MM 1142BP 140 0.8 5.5 50Hz
MM 1142BP 140 / 175 1.5 / 0.8 7.5
MM 1142BP 140 2 11.0 50Hz
MM 1142BP 175 2 12.6 60Hz
MM 1202AP 200 0.7 5.5 50Hz
MM 1202AP 200 / 240 1.2 / 0.7 7.5
MM 1202AP 200 2 11.0 50Hz
MM 1202AP 240 1 8.6 60Hz
MM 1202AP 240 1.8 12.6 60Hz
MM 1202AP 240 2 17.3 60Hz
MM 1252AP 250 0.9 7.5 50Hz
MM 1252AP 250 1.6 11.0 50Hz
MM 1252AP 250 2 15.0 50Hz
MM 1252AP 300 0.7 8.6 60Hz
MM 1252AP 300 1.4 12.6 60Hz
MM 1252AP 300 2 17.3 60Hz
MM 1322AP 300 1 11.0 50Hz
MM 1322AP 300 1.7 15.0 50Hz
MM 1322AP 300 2 18.5 50Hz
MM 1322AP 360 0.8 12.6 60Hz
MM 1322AP 360 1.5 17.3 60Hz
MM 1322AP 360 2 21.3 60Hz
MI 2124BV 50 / 60 20 1.5 / 2.2
MI 2122BV 120 / 145 20 4.0 / 5.5

Back to top

Busch  MM 1142BP

Merlin Rotary Claw Pressure-Vacuum Unit ME 2048 / 3048 D

Model  M3/H
50Hz / 60Hz		 Max Vacuum BAR (G)
50Hz / 60Hz		 Max Pressure BAR (G)
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
ME 2048D 80 0.6 0.7 2.2 / 2.6
ME 2048D 80 0.6 1 2.2 / 2.6
ME 2048D 140 0.6 0.7 4.0 / 4.0
ME 3048D 80 0.6 & 0.5 STAGE 2 0.7 3.0 / 3.6
ME 3048D 140 0.6 & 0.5 STAGE 2 0.8 5.5 / 5.5

Back to top

Busch  Merlin ME2048D

Dry Running Rotary Vane Vacuum OR Pressure Pumps

Model  M3/H
50Hz / 60Hz		 Max Vacuum mbar
50Hz / 60Hz		 Max Pressure BAR (G)
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
TINY SV1005C 4.6 / 5.5 150 0.14 / 0.18
TINY SD1005C 4.6 / 5.5 1 0.25 / 0.30
TINY SV1008C 7.3 / 8.8 150 0.25 / 0.30
TINY SD1008C 7.3 / 8.8 1 0.37 / 0.45
MINI SECO SV1004B 4 / 4.8 150 0.18 / 0.22
MINI SECO SD1004B 4 / 4.8 1 0.18 / 0.22
MINI SECO SV1006B 6 / 7.2 150 0.25 / 0.30
MINI SECO SD1006B 6 / 7.2 1 0.25 / 0.30
SECO SV1010C 10 / 12 150 0.37 / 0.37
SECO SD1010C 10 / 12 0.6 0.37 / 0.37
SECO SV1016C 16 / 19 150 0.55 / 0.55
SECO SD1016C 16 / 19 0.6 0.55 / 0.55
SECO SV1025C 25 / 30 120 0.9 / 0.9
SEDO SD1025C 25 / 30 0.6 / 1.0 0.9 / 1.1
SECO SV1040C 40 / 48 120 1.25 / 1.25
SECO SD1040C 40 / 48 0.6 / 1.0 1.25 / 1.5
SECO SV1063 63 / 75 100 1.7 / 2.2
SECO SD1063 63 / 75 2 2.2 / 2.2
SECO SV1080 80 / 96 100 2.2 / 3.0
SECO SD1080 80 / 96 2 3.0 / 3.0
SECO SV1100C 100 / 120 100 3.0 / 4.0
SECO SD1100D 100 / 120 2.5 5.5 / 7.5
SECO SV1140C 140 / 168 100 4.0 / 5.5
SECO SD1140C 140 / 168 2.5 7.5 / 9.0

Back to top

Busch  Seco SV1025C


Busch  Seco SV1080

Dry Running Rotary Vane Vacuum AND Pressure Pumps

Model  M3/H
50Hz / 60Hz		 Max Vacuum BAR (G)
50Hz / 60Hz		 Max Pressure BAR (G)
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
SECO PRINT DC0025C 25 / 30 0.6 0.6 1.1 / 1.1
SECO PRINT DC0040C 40 / 48 0.6 0.6 1.5 / 1.5
SECO PRINT DC0100C 100 / 120 0.6 0.6 4.0 / 5.5
SECO PRINT DC0140C 140 / 168 0.6 0.6 5.5 / 7.5

Back to top

SAMOS Side Channel Blowers

Model  M3/H
50Hz / 60Hz		 Max Vacuum mbar
50Hz / 60Hz		 Max Pressure mbar
50Hz / 60Hz		 Motor Size  KW
50Hz/60Hz
SE 0040C 45 / 55 70 60 0.1 / 0.12
SE 0085D 80 / 95 130 140 / 130 0.37 / 0.42
SE 0120C 140 / 170 125 120 0.75 / 0.86
SE 0170C 220 / 250 140 170 / 150 1.1 / 1.3
SE 0170C 220 / 250 190 / 170 210 / 170 1.5 / 1.7
SE 0300C 320 / 390 170 190 2.2 / 2.55
SE 0300C 320 / 390 220 275 3.0 / 3.45
SE 0420C 510 / 610 170 190 4.0 / 4.6
SE 0420C 510 / 610 240 250 5.5 / 6.4
SE 0905D 940 / 1130 180 / 150 170 / 135 5.5 / 6.3
SE 0905D 940 / 1130 240 / 220 235 / 205 7.5 / 8.7
SE 1105D 1100 / 1320 190 / 150 170 / 170 9.2 / 11.0
SE 1105D 1100 / 1320 315 / 330 400 18.5 / 22.2
SB 0050D0 50 / 60 90 / 120 100 / 130 0.2 / 0.23
SB 0080D0 80 / 100 110 / 100 110 / 100 0.25 / 0.30
SB 0080D0 80 / 100 120 / 150 130 / 160 0.4 / 0.5
SB 0140D0 140 / 175 120 / 130 120 / 130 0.7 / 0.8
SB 0200D0 210 / 250 170 / 150 170 / 140 1.3 / 1.5
SB 0200D0 210 / 250 200 / 220 190 / 210 1.6 / 2.1
SB 0310D0 315 / 375 210 / 210 200 / 200 2.2 / 2.6
SB 0310D0 315 / 375 270 / 260 290 / 250 3.0 / 3.5
SB 0430D0 415 / 500 160 / 130 150 / 120 2.2 / 2.6
SB 0430D0 415 / 500 230 / 210 220 / 190 3.0 / 3.5
SB 0430D0 415 / 500 290 / 300 310 / 280 4.0 / 4.6
SB 0530D0 530 / 620 200 / 160 200 / 160 4.0 / 4.6
SB 0530D0 530 / 620 300 / 300 300 / 280 5.5 / 6.3
SB 0710D0 700 / 840 150 / 90 140 / 90 4.0 / 4.6
SB 0710D0 700 / 840 200 / 180 190 / 180 5.5 / 6.3
SB 0710D0 700 / 840 270 260 7.5 / 8.6
SB 1100D0 1050 / 1250 190 / 150 190 / 140 8.5 / 9.8
SB 1100D0 1050 / 1250 290 / 270 280 / 260 12.5 / 14.5
SB 1100D0 1050 / 1250 360 / 380 460 / 420 18.5 / 21.3
SB 1400D0 1370 / 1645 120 / 80 110 / 70 8.5 / 9.8
SB 1400D0 1370 / 1645 210 / 180 190 / 160 12.5 / 14.5
SB 1400D0 1370 / 1645 310 / 300 320 / 280 18.5 / 21.5
SB 0080 D2 85 / 100 210 / 250 240 / 250 0.8 / 0.8
SB 0140D2 150 / 180 280 / 320 280 / 310 1.6 / 2.1
SB 0140D2 150 / 180 330 / 350 440 / 420 2.2 / 2.6
SB 0200D2 230 / 270 340 / 380 410 / 460 3.0 / 3.5
SB 0310D2 320 / 370 280 / 230 260 / 200 3.0 / 3.5
SB 0310D2 320 / 370 360 / 350 280 / 320 4.3 / 4.8
SB 0530D2 520 / 620 400 / 360 400 / 330 7.5 / 8.6
SB 1100D2 1120 / 1340 300 / 220 270 / 200 12.5 / 14.5
SB 1100D2 1120 / 1340 410 / 350 370 / 300 16.5 / 19.0
SB 1100D2 1120 / 1340 445 / 445 430 / 430 22.6 / 26.8

Back to top


Busch  Samos SE0430D0
