Becker Vacuum Pumps
Becker vacuum pumps, pressure pumps, combined vacuum and pressure pumps, technical specifications and support for current and older discontinued models.
Vacuum Pumps UK can help you identify an existing Becker pump, obtain a quotation for a Becker unit, source service support and spare parts, or assess suitable alternatives where availability, performance or operating requirements make comparison worthwhile.
Becker Pump Supply
Tell us the model, specification and electrical supply required and we will provide a quotation or confirm the information needed.
Model Identification
Use the current and discontinued model tables below, or send us a clear photograph of the pump nameplate for assistance.
Service & Spare Parts
Our sister company VacAir Superstore supports Becker pumps with servicing, carbon vanes, filters and spare parts.
Pump Comparison
Where appropriate, we can compare Becker pumps with carefully selected equivalent options for the application.
Becker Servicing, Vanes and Spare Parts
Our sister company, VacAir Superstore, provides workshop servicing, replacement carbon vanes, filters, service kits and spare parts for Becker dry-running, oil-lubricated, pressure and combined vacuum pumps. Support is available for both current and legacy Becker models.
Comparing a Becker Pump?
We can supply Becker vacuum pumps and, where appropriate, compare them with carefully selected DVP alternatives that are often more competitively priced and available from our extensive UK stock. Every recommendation is based on the required pumping speed, vacuum or pressure level, motor power, operating duty and installation conditions—not simply nominal capacity.
The examples below are commonly considered comparisons. Final pump selection should always be confirmed against the application and the full technical specification.
Becker KVT 3.140
Dry-running rotary vane vacuum pump
Dry-running rotary vane vacuum pump
Becker U 4.165
Oil-lubricated rotary vane vacuum pump
Oil-lubricated rotary vane vacuum pump
Becker U 4.250
Oil-lubricated rotary vane vacuum pump
Oil-lubricated rotary vane vacuum pump
Important: These are common starting points for comparison rather than confirmed drop-in replacements. Port sizes, dimensions, electrical requirements, ultimate vacuum, noise level and continuous-duty suitability must also be checked.
Becker Technical Reference Library
Choose a pump type below to jump directly to its specification table. Older models are retained because many remain installed and continue to require identification, servicing, parts or replacement.
Not sure which Becker model you have?
Send a clear photograph of the complete nameplate. Include the model, serial number, voltage, frequency and any suffix letters. Also tell us whether you need a new pump, a repair, spare parts or help selecting a suitable replacement.
Becker Dry-Running Rotary Vane Vacuum Pumps
Current VT, VX, KVT, KVX, VTLF and related Becker dry-running vacuum pump models.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum vacuum Abs 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|
| Becker VT 4.2 | 1.9 / 2.3 | 400 / 400 | 0.09 / 0.105 |
| Becker VT 4.4 | 4.1 / 4.7 | 150 / 150 | 0.18 / 0.21 |
| Becker VT 4.8 | 8 / 9.3 | 150 / 150 | 0.35 / 0.42 |
| Becker VT 4.10 | 10 / 12 | 150 / 150 | 0.37 / 0.45 |
| Becker VT 4.16 | 16 / 19 | 150 / 150 | 0.55 / 0.77 |
| Becker VT 4.25 | 25 / 30 | 150 / 150 | 0.75 / 0.90 |
| Becker VT 4.40 | 40 / 48 | 150 / 150 | 1.25 / 1.5 |
| Becker VX 3.6/08 | 7.5 / 9 | 150 / 150 | 0.25 / 0.3 |
| Becker VX 4.10 | 10 / 12 | 100 / 100 | 0.37 / 0.45 |
| Becker VX 4.16 | 16 / 19 | 100 / 100 | 0.55 / 0.77 |
| Becker VX 4.25 | 25 / 30 | 100 / 100 | 0.75 / 0.90 |
| Becker VX 4.40 | 40 / 48 | 100 / 100 | 1.25 / 1.5 |
| Becker KVT 3.60 | 55 / 66 | 100 / 100 | 2.4 / 3.0 |
| Becker KVT 3.80 | 67 / 78.5 | 100 / 100 | 2.4 / 3.0 |
| Becker KVT 3.100 | 98 / 112 | 100 / 100 | 3.0 / 3.5 |
| Becker KVT 3.140 | 132 / 154 | 100 / 200 | 4.0 / 4.8 |
| Becker KVX 3.60 | 55 / 66 | 100 / 100 | 2.4 / 3.0 |
| Becker KVX 3.80 | 67 / 78.5 | 100 / 100 | 2.4 / 3.0 |
| Becker KVX 3.100 | 98 / 112 | 100 / 100 | 3.0 / 3.5 |
| Becker KVX 3.140 | 132 / 154 | 100 / 200 | 4.0 / 4.8 |
| Becker VTLF 2.200 | 178 / 218 | 200 / 200 | 4.0 / 4.8 |
| Becker VTLF 2.250 | 244 / 286 | 200 / 200 | 5.5 / 6.40 |
| Becker VTLF 2.360 | 351 / 402 | 250 / 250 | 11.0 / 13.2 |
| Becker VTLF 2.400 | 390 / 460 | 200 / 200 | 7.5 / 8.6 |
| Becker VTLF 2.500 | 495 / 570 | 250 / 250 | 11.0 / 12.6 |
| Becker VXLF 2.200 | 178 / 218 | 200 / 200 | 4.0 / 4.8 |
| Becker VXLF 2.250 | 244 / 286 | 200 / 200 | 5.5 / 6.4 |
| Becker VXLF 2.400 | 390 / 460 | 200 / 200 | 7.5 / 8.6 |
| Becker VXLF 2.500 | 495 / 570 | 250 / 250 | 11.0 / 12.60 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Older Becker Dry-Running Vacuum Pumps
Older VT, KVT, VTLF and VXLF models retained for identification, servicing and replacement enquiries.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum vacuum Abs 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|
| Becker VT 3.3 | 3 / 3.6 | 150 / 150 | 0.15 / 0.18 |
| Becker VT 3.6/08 | 6 / 7.2 | 150 / 150 | 0.25 / 0.30 |
| Becker VT 3.10 | 10 / 12 | 150 / 100 | 0.37 / 0.45 |
| Becker VT 3.16 | 16 / 19.2 | 150 / 100 | 0.55 / 0.66 |
| Becker VT 3.25 | 25 / 30 | 150 / 100 | 0.75 / 0.9 |
| Becker VT 3.40 | 40 / 48 | 150 / 100 | 1.25 / 1.5 |
| Becker Picchio 2200 | 90 / 108 | 100 / 100 | 2.4 / 3.0 |
| Becker KVT 2.60 | 55 / 64 | 80 / 80 | 1.5 / 1.8 |
| Becker KVT 2.80 | 68 / 80 | 80 / 80 | 2.2 / 2.64 |
| Becker KVT 3.100 | 100 / 116 | 80 / 80 | 3.0 / 3.6 |
| Becker KVT 3.140 | 135 / 160 | 80 / 80 | 4.0 / 4.8 |
| Becker VTLF 200 | 178 / 218 | 200 / 200 | 4.0 / 4.8 |
| Becker VTLF 250 | 248 / 300 | 200 / 200 | 5.5 / 6.4 |
| Becker VTLF 360 | 350 / – | 250 / 250 | 11 / – |
| Becker VTLF 400 | 372 / 451 | 200 / 200 | 11 / 12.5 |
| Becker VTLF 500 | 498 / 600 | 250 / 250 | 15 / 16.5 |
| Becker VXLF 200 | 178 / 215 | 200 / 200 | 4.0 / 4.8 |
| Becker VXLF 250 | 248 / 300 | 200 / 200 | 5.5 / 6.4 |
| Becker VXLF 400 | 372 / 451 | 200 / 200 | 11 / 12.5 |
| Becker VXLF 500 | 498 / 600 | 250 / 250 | 15 / 16.5 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Becker Dry-Running Rotary Vane Pressure Pumps
Current DT, DX, KDT, KDX, DTLF and DXLF pressure pump models.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum pressure 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|
| Becker DT 4.2 | 1.9 / 2.3 | 0.60 | 0.09 / 0.105 |
| Becker DT 4.4 | 4.2 / 4.9 | 1.00 | 0.18 / 0.21 |
| Becker DT 4.6/0-61 | 5.7 / 6.4 | 0.50 | 0.18 / 0.21 |
| Becker DT 4.8 | 8.0 / 9.5 | 1.00 | 0.37 / 0.44 |
| Becker DT 4.10 | 10 / 12 | 1.00 | 0.37 / 0.45 |
| Becker DX 4.10 | 10 / 12 | 1.00 | 0.37 / 0.45 |
| Becker DT 4.16 | 16 / 19 | 1.00 | 0.55 / 0.70 |
| Becker DX 4.16 | 16 / 19 | 1.00 | 0.55 / 0.70 |
| Becker DT 4.25K | 25 / 30 | 1.00 | 1.1 / 1.3 |
| Becker DX 4.25K | 25 / 30 | 1.00 | 1.1 / 1.3 |
| Becker DT 4.40K | 40 / 48 | 1.00 | 1.85 / 2.2 |
| Becker DX 4.40K | 40 / 48 | 1.00 | 1.85 / 2.2 |
| Becker KDT 3.60 | 54 / 63 | 1* or 1.5 | 2.2 / 2.6* – 3.0 / 3.6 |
| Becker KDX 3.60 | 54 / 63 | 1* or 1.5 | 2.2 / 2.6* – 3.0 / 3.6 |
| Becker KDT 3.80 | 66 / 77 | 1* or 1.5 | 3.0 / 3.6* – 4.0 / 4.8 |
| Becker KDX 3.80 | 66 / 77 | 1* or 1.5 | 3.0 / 3.6* – 4.0 / 4.8 |
| Becker KDT 3.100 | 99 / 118 | 1* or 1.5 | 4.0 / 4.8* – 5.5 / 6.6 |
| Becker KDX 3.100 | 99 / 118 | 1* or 1.5 | 4.0 / 4.8* – 5.5 / 6.6 |
| Becker KDT 3.140 | 129 / 153 | 1* or 1.5 | 5.5 / 6.6* – 7.5 / 9.0 |
| Becker KDX 3.140 | 129 / 153 | 1* or 1.5 | 5.5 / 6.6* – 7.5 / 9.0 |
| DTLF 2.200 | 174 / 216 | 0.8 | 5.5 / 6.6 |
| 1.0 | 7.5 / 9.0 | ||
| 1.8 | 11.0 / 13.2 | ||
| DXLF 2.200 | 174 / 216 | 0.8 | 5.5 / 6.6 |
| 1.0 | 7.5 / 9.0 | ||
| 1.8 | 11.0 / 13.2 | ||
| DTLF 2.250 | 247 / 294 | 0.8 | 7.5 / 9.0 |
| 1.0 | 11.0 / 13.2 | ||
| 1.8 | 15.0 / 18.0 | ||
| DXLF 2.250 | 247 / 294 | 0.8 | 7.5 / 9.0 |
| 1.0 | 11.0 / 13.2 | ||
| 1.8 | 15.0 / 18.0 | ||
| DTLF 2.360 | 360 | 0.5 | 11 (50Hz Unit Only) |
| 0.9 | 15 (50Hz Unit Only) | ||
| DTLF 2.400 | 365 / 440 | 0.9 | 11.0 / 13.2 |
| 1.25 | 15.0 / 18.0 | ||
| 1.8 | 18.5 / 22.0 | ||
| DXLF 2.400 | 365 / 400 | 0.9 | 11.0 / 13.2 |
| 1.25 | 15.0 / 18.0 | ||
| 1.8 | 18.5 / 22.0 | ||
| DTLF 2.500 | 515 / 600 | 0.8 | 15.0 / 18.0 |
| 1.1 | 18.5 / 22.0 | ||
| 1.5 | 22.0 / 25.9 (26) | ||
| 1.8 | 30.0 / 36.0 | ||
| DXLF 2.500 | 515 / 600 | 0.8 | 15.0 / 18.0 |
| 1.1 | 18.5 / 22.0 | ||
| 1.5 | 22.0 / 25.9 (26) | ||
| 1.8 | 30.0 / 36.0 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Older Becker Dry-Running Pressure Pumps
Older Becker pressure pump models retained as a technical reference for installed equipment.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum pressure 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|
| DT3.3 | 3 / 3.6 | 1 | 0.15 / 0.18 |
| DT3.6/08 | 6 / 7.2 | 1.2 | 0.25 / 0.30 |
| DT3.10 | 10.1 / 12.3 | 1 | 0.37 / 0.44 |
| DT3.16 | 16 / 19.2 | 1 | 0.55 / 0.70 |
| DT3.25K | 25 / 30 | 1 | 1.1 / 1.13 |
| DT3.40K | 40 / 48 | 1 | 1.85 / 2.2 |
| KDT2.60 | 58 / 65 | 0.5 | 1.5 / 1.8 |
| 1.1 | 2.2 / 2.64 | ||
| 1.5 | 3.0 / 3.6 | ||
| KDT2.80 | 69 / 82 | 0.5 | 2.2 / 2.64 |
| 1.1 | 3.0 / 3.6 | ||
| 1.5 | 4.0 / 4.8 | ||
| KDT2.100 | 97 / 117 | 0.5 | 3.0 / 3.6 |
| 1.1 | 4.0 / 4.8 | ||
| 1.5 | 5.5 / 6.6 | ||
| KDT2.140 | 137 / 159 | 0.5 | 4.0 / 4.8 |
| 1.1 | 5.5 / 6.6 | ||
| 1.5 | 7.5 / 9.0 | ||
| DTLF200 | 174 / 215 | 0.8 | 5.5 / 6.3 |
| 1.5 | 7.5 / 8.6 | ||
| 2.0 | 11.0 / 12.5 | ||
| DTLF250 | 245 / 294 | 0.8 | 7.5 / 8.6 |
| 1.5 | 11.0 / 12.5 | ||
| 2.0 | 15.0 / 16.5 | ||
| DTLF360 | 350 | 0.5 | 11 (50Hz Units Only) |
| 0.9 | 15 (50Hz Units Only) | ||
| 1.4 | 18.5 (50Hz Units Only) | ||
| 1.8 | 22 (50Hz Units Only) | ||
| DTLF400 | 363 / 448 | 1.0 | 15 (50Hz Units Only) |
| 2.0 | 18.5 (50Hz Units Only) | ||
| DTLF500 | 500 / 600 | 0.5 | 15.0 / 16.5 |
| 0.8 | 18.5 (50Hz Units Only) | ||
| 1.0 | 22 (50Hz Units Only) | ||
| 1.8 | 30 (50Hz Units Only) | ||
| DXLF200 | 174 / 216 | 0.8 | 5.5 / 6.3 |
| 1.5 | 7.5 / 8.6 | ||
| 2.0 | 11 / 12.5 | ||
| DXLF250 | 245 / 294 | 0.8 | 7.5 / 8.6 |
| 1.5 | 11.0 / 12.65 | ||
| 2 | 15.0 / 16.5 | ||
| DXLF400 | 363 / 448 | 1 | 15 (50Hz Units Only) |
| 2 | 18.5 (50Hz Units Only) | ||
| DXLF500 | 500 / 600 | 0.5 | 15.0 / 16.5 |
| 0.8 | 18.5 (50Hz Units Only) | ||
| 1 | 22 (50Hz Units Only) | ||
| 1.8 | 30 (50Hz Units Only) |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Becker Oil-Lubricated Rotary Vane Vacuum Pumps
Current Becker O5, U4 and related oil-lubricated vacuum pump models.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum vacuum 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|
| Becker O6.4 | 4 / 4.8 | 3 / 3 | 0.10 / 0.12 |
| Becker O5.6 | 6.4 / 7.4 | 2 / 2 | 0.30 / 0.36 |
| Becker O6.8 | 8 / 9.6 | 2 / 2 | 0.35 / 0.45 |
| Becker O5.10 | 10 / 12 | 2 / 2 | 0.37 / 0.45 |
| Becker O5.16 | 16 / 19 | 2 / 2 | 0.55 / 0.70 |
| Becker O5.21 | 23.5 / 27 | 2 / 2 | 0.75 / 0.90 |
| Becker U4.20 | 18 / 21 | 1.0 / 1.5 | 0.55 / 0.66 |
| Becker U4.40 | 41 / 48 | 0.5 / 0.5 | 1.5 / 1.8 |
| Becker U4.165 SA/K | 162 / 190 | 3.0 / 3.0 | 4.0 / 4.8 |
| Becker U4.165 F/K | 162 / 190 | 0.5 / 0.5 | 4.0 / 4.8 |
| Becker U4.190 SA/K | 190 / 223 | 3.0 / 3.0 | 5.5 / 6.4 |
| Becker U4.190 F/K | 190 / 223 | 0.5 / 0.5 | 5.5 / 6.4 |
| Becker U4.250 SA/K | 244 / 276 | 3.0 / 3.0 | 7.8 / 9.3 |
| Becker U4.250 F/K | 244 / 276 | 0.5 / 0.5 | 7.8 / 7.3 |
| Becker U4.300 | 300 / 360 | 0.5 / 0.5 | 7.5 / 8.6 |
| Becker U4.400 SA/K | 435 / 508 | 3.0 / 3.0 | 11.0 / 12.5 |
| Becker U4.400 F/K | 435 / 508 | 0.5 / 0.5 | 11.0 / 12.5 |
| Becker U4.630 SA/K | 624 / 732 | 3.0 / 3.0 | 15.0 / 18.5 |
| Becker U4.630 F/K | 624 / 732 | 0.5 / 0.5 | 15.0 / 18.5 |
| Becker U5.40 (XL K) | 40 / 48 | 0.5 / 0.5 | 1.1 / 1.35 |
| Becker U5.45 | 45 / 54 | 0.5 / 0.5 | 1.5 / 1.8 |
| Becker U5.65 (XL K) | 65 / 78 | 0.5 / 0.5 | 1.5 / 1.8 |
| Becker U5.70 | 70 / 84 | 0.1 / 0.1 | 1.5 / 1.8 |
| Becker U5.71 | 71 / 84 | 0.1 / 0.1 | 1.5 / 1.8 |
| Becker U5.100 | 100 / 120 | 0.1 / 0.1 | 2.2 / 2.6 |
| Becker U5.101 | 100 / 120 | 0.1 / 0.1 | 2.2 / 2.6 |
| Becker U5.165 | 165 / 198 | 0.1 / 0.1 | 4.0 / 4.8 |
| Becker U5.166 | 165 / 198 | 0.1 / 0.1 | 3.0 / 3.6 |
| Becker U5.200 | 200 / 240 | 0.1 / 0.1 | 5.5 / 6.6 |
| Becker U5.201 | 200 / 240 | 0.1 / 0.1 | 5.5 / 6.6 |
| Becker U5.300 | 300 / 360 | 0.1 / 0.1 | 5.5 / 6.6 |
| Becker U5.301 | 300 / 360 | 0.1 / 0.1 | 5.5 / 6.6 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Older Becker Oil-Lubricated Vacuum Pumps
Older oil-lubricated Becker models retained for identification, service and replacement support.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum vacuum 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|
| Becker U1.16 SA | 16 / 19 | 3 | 0.55 / 0.66 |
| Becker U3.10 SA | 10 / 12 | 3 | 0.37 / 0.45 |
| Becker U3.10 SB | 10 / 12 | 20 | 0.37 / 0.45 |
| Becker U3.16 SA | 16 / 19 | 3 | 0.55 / 0.66 |
| Becker U3.16 SB | 16 / 19 | 20 | 0.55 / 0.66 |
| Becker U3.25 SA | 28 / 34 | 3 | 0.75 / 0.90 |
| Becker U3.25 SB | 28 / 34 | 20 | 0.75 / 0.90 |
| Becker U3.40 SA | 40 / 47 | 3 | 1.1 / 1.3 |
| Becker U3.40 SB | 40 / 47 | 20 | 1.1 / 1.3 |
| Becker U2.70 SA | 70 | 3 | 1.5* |
| Becker U2.70 SB | 70 | 20 | 1.5* |
| Becker U2.70 SF | 70 | 0.5 | 1.5* |
| Becker U2.100 SA | 105 | 3 | 2.2* |
| Becker U2.100 SB | 105 | 20 | 2.2* |
| Becker U2.100 SF | 105 | 0.5 | 2.2* |
| Becker U2.165 SA | 160 | 3 | 3* |
| Becker U2.165 SB | 160 | 20 | 3* |
| Becker U2.165 SF | 160 | 0.5 | 3* |
| Becker U2.190 SA | 184 | 3 | 4* |
| Becker U2.190 SB | 184 | 20 | 4* |
| Becker U2.190 SF | 184 | 0.5 | 4* |
| Becker U2.250 SA | 245 | 3 | 5.5* |
| Becker U2.250 SB | 245 | 20 | 5.5* |
| Becker U2.250 SF | 245 | 0.5 | 5.5* |
| Becker U4.70 SA/K | 63 / 74 | 3 | 2.4 / 3.0 |
| Becker U4.70 F/K | 63 / 74 | 0.5 | 2.4 / 3.0 |
| Becker U4.100 SA/K | 100 / 117 | 3 | 2.4 / 3.0 |
| Becker U4.100 F/K | 100 / 117 | 0.5 | 2.4 / 3.0 |
| Becker U4.165 SA/K | 162 / 190 | 3 | 4.0 / 4.8 |
| Becker U4.165 F/K | 162 / 190 | 0.5 | 4.0 / 4.8 |
| Becker U4.190 SA/K | 190 / 223 | 3 | 5.5 / 6.6 |
| Becker U4.190 F/K | 190 / 223 | 0.5 | 5.5 / 6.6 |
| Becker U4.250 SA/K | 244 / 276 | 3 | 7.5 / 9.0 |
| Becker U4.250 F/K | 244 / 276 | 0.5 | 7.5 / 9.0 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Becker Combined Vacuum and Pressure Pumps
Current Becker combined vacuum and pressure rotary vane pump models.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum vacuum 50Hz / 60Hz |
Max Pressure mbar Abs 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|---|
| Becker T4.10DV | 10 / 12 | 500 | 500 | 0.37 / 0.45 |
| Becker X4.10DV | 10 / 12 | 500 | 500 | 0.37 / 0.45 |
| Becker T4.16DV | 16 / 20 | 500 | 500 | 0.55 / 0.70 |
| Becker X4.16DV | 16 / 20 | 500 | 500 | 0.55 / 0.70 |
| Becker T4.25DV | 25 / 30 | 500 | 500 | 0.75 / 0.90 |
| Becker X4.25DV | 25 / 30 | 500 | 500 | 0.75 / 0.90 |
| Becker T4.25DSK | 25 / 30 | 600 | 600 | 1.1 / 1.3 |
| Becker X4.25DSK | 25 / 30 | 600 | 600 | 1.1 / 1.3 |
| Becker T4.40DV | 35 / 43 | 500 | 500 | 1.25 / 1.5 |
| Becker X4.40DV | 35 / 43 | 500 | 500 | 1.25 / 1.5 |
| Becker T4.40DSK | 35 / 43 | 600 | 600 | 1.85 / 2.2 |
| Becker X4.40DSK | 35 / 43 | 600 | 600 | 1.85 / 2.2 |
| Becker DVT3.60 | 58 / 69 | 600 | 600 | 3.0 / 3.6 |
| Becker DVX3.60 | 58 / 69 | 600 | 600 | 3.0 / 3.6 |
| Becker DVT3.80 | 70 / 82 | 600 | 600 | 4.0 / 4.8 |
| Becker DVX3.80 | 70 / 82 | 600 | 600 | 4.0 / 4.8 |
| Becker DVT3.100 | 103 / 120 | 600 | 600 | 5.5 / 6.6 |
| Becker DVX3.100 | 103 / 120 | 600 | 600 | 5.5 / 6.6 |
| Becker DVT3.140 | 137 / 160 | 600 | 600 | 7.5 / 9.0 |
| Becker DVX3.140 | 137 / 160 | 600 | 600 | 7.5 / 9.0 |
| Becker DVTLF2.250K | 242 / 287 | 500 | 500 | 7.5 / 9.0 |
| Becker DVTLF2.400 | 380 / 455 | 500 | 500 | 11.0 / 12.5 |
| Becker DVTLF2.500 | 500 / 578 | 500 | 500 | 15.0 / 17.30 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Older Becker Combined Vacuum and Pressure Pumps
Older combined vacuum and pressure models retained for technical reference and support.
| Model | Nominal capacity 50Hz / 60Hz |
Maximum vacuum 50Hz / 60Hz |
Max Pressure mbar Abs 50Hz / 60Hz |
Motor power 50Hz/60Hz |
|---|---|---|---|---|
| T3.16DSK | 16 / 19 | 600 | 600 | 0.55 / 0.70 |
| T3.25DSK | 25 / 30 | 600 | 600 | 1.1 / 1.13 |
| T3.40DSK | 40 / 48 | 600 | 600 | 1.85 / 2.2 |
| T3.60DSK | 60 / 68 | 600 | 600 | |
| Becker DVT2.60 | 55 / 64 | 600 | 600 | 2.2 / 2.64 |
| Becker DVT2.80 | 68 / 80 | 600 | 600 | 3.0 / 3.6 |
| Becker DVT2.100 | 100 / 116 | 600 | 600 | 4.0 / 4.8 |
| Becker DVT2.140 | 135 / 160 | 600 | 600 | 5.5 / 6.6 |
Figures are shown at 50 Hz / 60 Hz where applicable. Specifications can vary by version and production year; please contact Vacuum Pumps UK to confirm the correct pump for your equipment or application.
Becker SV Side Channel Blowers
Becker SV side channel blowers provide oil-free vacuum or positive-pressure airflow for industrial applications including printing and paper handling, packaging machinery, pneumatic conveying, vacuum lifting, drying, cooling, aeration and general mechanical engineering.
The Becker SV range includes single-stage and double-stage side channel blowers in a wide selection of airflow and motor configurations. The tables below show the 50 Hz nominal airflow, motor power, maximum relative vacuum and maximum relative pressure for each configuration.
Becker SV Single-Stage Side Channel Blowers
Single-stage SV blowers provide higher airflow for general industrial vacuum and positive-pressure duties. Different motor ratings within the same blower model can provide substantially different maximum vacuum and pressure capabilities.
| Model Number | Air Flow m³/h |
Motor Size kW |
Max Vacuum mbar |
Max Pressure mbar |
|---|---|---|---|---|
| SV 5.90/1 0.37 kW | 75 | 0.37 | -120 | +100 |
| SV 5.130/1 0.75 kW | 130 | 0.75 | -125 | +130 |
| SV 5.190/1 2.2 kW | 180 | 2.2 | -200 | +180 |
| SV 5.250/1 2.2 kW | 231 | 2.00 | -190 | +190 |
| SV 5.300/1 4.0 kW | 325 | 4.0 | -300 | +260 |
| SV 5.300/1 5.50 kW | 325 | 5.50 | -350 | +430 |
| SV 5.330/1 4.0 kW | 300 | 4.0 | -300 | +300 |
| SV 5.430/1 4.0 kW | 460 | 4.0 | -200 | +200 |
| SV 5.490/1 5.50 kW | 480 | 5.50 | -300 | +280 |
| SV 5.490/1 7.50 kW | 472 | 7.50 | -300 | +410 |
| SV 5.690/1 7.5 kW | 720 | 7.5 | -320 | +280 |
| SV 5.690/1 11.00 kW | 720 | 11.00 | -330 | +410 |
| SV 5.1050/1 11.00 kW | 1080 | 11.00 | -180 | +160 |
| SV 5.1050/1 15.00 kW | 1080 | 15.00 | -265 | +365 |
| SV 7.190/1 2.2 kW | 180 | 2.2 | -275 | +210 |
| SV 7.330/1 4.00 kW | 290 | 4.00 | -275 | +360 |
| SV 7.380/1 4.00 kW | 360 | 4.00 | -225 | +275 |
| SV 7.430/1 4.00 kW | 415 | 4.00 | -240 | +220 |
| SV 8.130/1 1.25 kW | 120 | 1.25 | -200 | +250 |
| SV 8.160/1 1.50 kW | 145 | 1.50 | -200 | +225 |
| SV 8.190/1 1.5 kW | 180 | 1.5 | -210 | +205 |
| SV 8.190/1 2.00 kW | 181 | 2.00 | -250 | +285 |
| SV 8.400/1 5.50 kW | 410 | 5.50 | -300 | +330 |
| SV 130/1 0.55 kW | 130 | 0.55 | -75 | +75 |
| SV 130/1 0.75 kW | 130 | 0.75 | -125 | +125 |
| SV 130/1 1.10 kW | 130 | 1.10 | -210 | +210 |
| SV 130/1 1.25 kW | 130 | 1.25 | -240 | +240 |
| SV 130/1 1.50 kW | 130 | 1.50 | -240 | +280 |
| SV 200/1 1.10 kW | 180 | 1.10 | -150 | +145 |
| SV 200/1 1.50 kW | 180 | 1.50 | -215 | +225 |
| SV 201/1 1.10 kW | 190 | 1.10 | -140 | +135 |
| SV 201/1 1.50 kW | 190 | 1.50 | -220 | +210 |
| SV 201/1 2.20 kW | 190 | 2.20 | -275 | +340 |
| SV 300/1 2.20 kW | 325 | 2.20 | -170 | +165 |
| SV 300/1 3.00 kW | 325 | 3.00 | -265 | +250 |
| SV 300/1 4.00 kW | 325 | 4.00 | -290 | +340 |
| SV 400/1 3.00 kW | 390 | 3.00 | -210 | +200 |
| SV 400/1 4.00 kW | 390 | 4.00 | -315 | +290 |
| SV 400/1 5.50 kW | 390 | 5.50 | -315 | +425 |
| SV 500/1 4.00 kW | 510 | 4.00 | -200 | +190 |
| SV 500/1 5.50 kW | 510 | 5.50 | -315 | +295 |
| SV 500/1 7.50 kW | 510 | 7.50 | -355 | +435 |
| SV 700/1 5.50 kW | 750 | 5.50 | -200 | +185 |
| SV 700/1 7.50 kW | 750 | 7.50 | -300 | +285 |
| SV 700/1 11.00 kW | 750 | 11.00 | -360 | +400 |
| SV 1100/1 7.50 kW | 1050 | 7.50 | -160 | +140 |
| SV 1100/1 11.00 kW | 1050 | 11.00 | -290 | +260 |
| SV 1100/1 15.00 kW | 1050 | 15.00 | -320 | +390 |
Becker SV Double-Stage Side Channel Blowers
Double-stage Becker SV blowers provide lower nominal airflow than comparable single-stage units but can operate against a significantly greater vacuum or positive-pressure differential. They are suited to applications where stronger suction or discharge pressure is required.
| Model Number | Air Flow m³/h |
Motor Size kW |
Max Vacuum mbar |
Max Pressure mbar |
|---|---|---|---|---|
| SV 5.90/2 0.37 kW | 40 | 0.37 | -230 | +250 |
| SV 5.130/2 1.1 kW | 70 | 1.1 | -380 | +400 |
| SV 5.190/2 1.1 kW | 100 | 1.1 | -275 | +290 |
| SV 5.250/2 2.2 kW | 130 | 2.2 | -400 | +400 |
| SV 5.300/2 5.5 kW | 260 | 5.5 | -400 | +370 |
| SV 5.330/2 3 kW | 180 | 3.0 | -330 | +330 |
| SV 5.690/2-500 7.50 kW | 375 | 7.50 | -400 | +500 |
| SV 5.1050/2 11 kW | 530 | 11 | -480 | +500 |
| SV 7.190/2 2.2 kW | 90 | 2.2 | -330 | +330 |
| SV 7.330/2 3.00 kW | 156 | 3.00 | -400 | +475 |
| SV 7.330/2 4.00 kW | 180 | 4.00 | -410 | +440 |
| SV 7.430/2 4.00 kW | 235 | 4.00 | -325 | +430 |
| SV 8.130/2 1.25 kW | 65 | 1.25 | -300 | +425 |
| SV 8.160/2 1.50 kW | 75 | 1.50 | -300 | +400 |
| SV 8.190/2 1.5 kW | 98 | 1.5 | -325 | +320 |
| SV 8.190/2 2.00 kW | 98 | 2.00 | -375 | +430 |
| SV 8.400/2 5.50 kW | 210 | 5.50 | -400 | +450 |
| SV 130/2 0.55 kW | 70 | 0.55 | -170 | +160 |
| SV 130/2 0.75 kW | 70 | 0.75 | -270 | +250 |
| SV 130/2 1.10 kW | 70 | 1.10 | -380 | +400 |
| SV 200/2 1.10 kW | 90 | 1.10 | -330 | +300 |
| SV 200/2 1.50 kW | 90 | 1.50 | -330 | +410 |
| SV 201/2 1.10 kW | 90 | 1.10 | -280 | +260 |
| SV 201/2 1.50 kW | 90 | 1.50 | -400 | +420 |
| SV 300/2 2.20 kW | 160 | 2.20 | -350 | +330 |
| SV 300/2 3.00 kW | 160 | 3.00 | -405 | +515 |
| SV 400/2 3.00 kW | 195 | 3.00 | -440 | +390 |
| SV 400/2 4.00 kW | 195 | 4.00 | -440 | +530 |
| SV 500/2 3.00 kW | 260 | 3.00 | -280 | — |
| SV 500/2 4.00 kW | 260 | 4.00 | -410 | +370 |
| SV 500/2 5.50 kW | 260 | 5.50 | -410 | +480 |
| SV 700/2 5.50 kW | 375 | 5.50 | -390 | +330 |
| SV 700/2 7.50 kW | 375 | 7.50 | -400 | +500 |
| SV 1100/2 7.50 kW | 520 | 7.50 | -350 | +260 |
| SV 1100/2 11.00 kW | 520 | 11.00 | -390 | +500 |
Becker SV Multi-Stage Side Channel Blower
| Model Number | Air Flow m³/h |
Motor Size kW |
Max Vacuum mbar |
Max Pressure mbar |
|---|---|---|---|---|
| SV 1.50/3 0.18 kW | 41 | 0.18 | -100 | +100 |
Performance figures: Airflow, motor power, maximum vacuum and maximum pressure figures shown are 50 Hz values. Vacuum and pressure values are relative. Exact performance should be confirmed against the individual blower specification and operating duty.
Frequently Asked Questions
Can Vacuum Pumps UK supply Becker vacuum pumps?
Yes. Vacuum Pumps UK can provide quotations for Becker vacuum pumps and help identify the correct model, specification and electrical version for an existing installation or new application.
Can you help identify an older Becker pump?
Yes. The legacy model tables on this page cover many older Becker vacuum, pressure and combined pump ranges. A clear photograph of the pump nameplate is usually the best starting point.
Can older Becker vacuum pumps still be serviced?
Many older Becker pumps can still be serviced or repaired, subject to condition and parts availability. Our sister company VacAir Superstore provides Becker servicing, carbon vanes and spare parts.
Can another pump replace a Becker model?
In many applications an alternative pump can be selected by comparing capacity, operating vacuum or pressure, motor size, duty cycle, port arrangement and installation dimensions. We can assess the application and advise whether a direct replacement or engineered alternative is suitable.
What information is needed for a Becker pump quotation?
Please provide the complete model and serial number from the nameplate, voltage and frequency, required quantity and whether the enquiry is for a new pump, replacement, service or spare parts.
Do you supply Becker spare parts and carbon vanes?
Becker spare parts, filters, carbon vanes and servicing are available through our sister company VacAir Superstore, which supports both current and legacy Becker models.
Need Help Choosing The Right Vacuum Pump?
Our experienced team can help with replacement pumps, new installations, servicing, spare parts and vacuum problems. Call us today for friendly technical advice and a competitive quotation.
